| Model No.: | SUN-3K-6K SG04LP1-24-EU-SM1-SM2 |
| Battery Voltage Range (V) | 20-60 |
| Battery Type: | Lead-acid or Lithium-ion |
| Number of Battery Input: | 1 |
| Max. PV Access Power (W)： | 12000 |
| Max. PV Input Power (W) | 9600 |
| MPPT Voltage Range (V)： | 150-425 |
| Warranty： | 5 Years/10 Years |
Performance Parameter
| Model | SUN-3K-SG04LP1-24-EU-SM1 | SUN-3K-SG04LP1-EU-SM1 | SUN-3.6K-SG04LP1-EU-SM2 | SUN-5K-SG04LP1-EU-SM2 | SUN-6K-SG04LP1-EU-SM2 |
| Battery Input Data | |||||
| Battery Type | Lead-acid or Lithium-ion | ||||
| Battery Voltage Range (V) | 20-30 | 40-60 | 40-60 | 40-60 | 40-60 |
| Max. Charging Current (A) | 140 | 70 | 90 | 120 | 135 |
| Max. Discharging Current (A) | 140 | 70 | 90 | 120 | 135 |
| Charging Strategy for Li-ion Battery | Self-adaption to BMS | ||||
| Number of Battery Input | 1 | ||||
| PV String Input Data | |||||
| Max. PV Access Power (W) | 6000 | 6000 | 7200 | 10000 | 12000 |
| Max. PV Input Power (W) | 4800 | 4800 | 5760 | 8000 | 9600 |
| Max. PV Input Voltage (V) | 500 | ||||
| Start-up Voltage (V) | 125 | ||||
| MPPT Voltage Range (V) | 150-425 | ||||
| Rated PV Input Voltage (V) | 370 | ||||
| Max. Operating PV Input Current (A) | 18 | 18+18 | |||
| Max. Input Short-Circuit Current (A) | 27 | 27+27 | |||
| No. of MPP Trackers/ No. of Strings MPP Tracker |
1/1 | 2/1+1 | |||
| AC Input/Output Data | |||||
| Rated AC Input/Output Active Power (W) | 3000 | 3600 | 5000 | 6000 | |
| Max. AC Input/Output Apparent Power (VA) | 3300 | 3960 | 5500 | 6600 | |
| Rated AC Input/Output Current (A) | 13.7/13.1 | 16.4/15.7 | 22.8/21.8 | 27.3/26.1 | |
| Max. AC Input/Output Current (A) | 15/14.4 | 18/17.3 | 25/24 | 30/28.7 | |
| Max. Continuous AC Passthrough (grid to load) (A) | 35 | 40 | |||
| Peak Power (off-grid) (W) | 2 times of rated power, 10s | ||||
| Power Factor Adjustment Range | 0.8 leading to 0.8 lagging | ||||
| Rated Input/Output Voltage/Range (V) | 220/230 0.85Un-1.1Un | ||||
| Rated Input/Output Grid Frequency/Range(Hz) | 50/45-55, 60/55-65 | ||||
| Grid Connection Form | L+N+PE | ||||
| Total Current Harmonic Distortion THDi | <3% (of nominal power) | ||||
| DC Injection Current | <0.5% In | ||||
| Efficiency | |||||
| Max. Efficiency | 97.60% | ||||
| Euro Efficiency | 96.50% | ||||
| MPPT Efficiency | >99% | ||||
| Equipment Protection | |||||
| Integrated | DC Polarity Reverse Connection Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring, Overvoltage Load Drop Protection, Ground Fault Current Monitoring, Arc Fault Circuit Interrupter (optional), Power Network Monitoring, Island Protection Monitoring, Earth Fault Detection, DC Input Switch, DC Terminal Insulation Impedance Monitoring, Residual Current (RCD) Detection, Surge protection level |
||||
| Surge Protection Level | TYPE II(DC), TYPE II(AC) | ||||
| Interface | |||||
| Communication Interface | RS485/RS232/CAN | ||||
| Monitor Mode | GPRS/WIFI/Bluetooth/4G/LAN(optional) | ||||
| General Data | |||||
| Operating Temperature Range (℃) | -40 to +60℃, >45℃ Derating | ||||
| Permissible Ambient Humidity | 0-100% | ||||
| Permissible Altitude | 2000m | ||||
| Noise (dB) | <30 | ||||
| Ingress Protection(IP) Rating | IP 65 | ||||
| Inverter Topology | Non-Isolated | ||||
| Over Voltage Category | OVC II(DC), OVC III(AC) | ||||
| Cabinet Size (WxHxD mm) | 376×470×241.5 (Excluding Connectors and Brackets) | ||||
| Weight (kg) | 17.6 | 19 | |||
| Type of Cooling | Natural Cooling | ||||
| Warranty | 5 Years/10 Years the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy |
||||
| Grid Regulation | IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 |
||||
| Safety / EMC Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | ||||
Partner Brands List
FAQ
1. Why is a hybrid inverter the best choice for my home solar system?
A hybrid inverter is the intelligent brain of your energy system, seamlessly managing solar power, battery storage, and grid electricity to maximize savings and provide reliable backup power during outages. Unlike standard inverters, it gives you full control over your energy usage.
2. Can this inverter power my home during a blackout?
Yes! The Deye hybrid inverter provides seamless backup power in under 20 milliseconds when the grid fails, keeping your lights, refrigerator, and essential appliances running smoothly. You'll need a compatible battery system for this backup functionality.
3. What makes Deye inverters more reliable than other brands?
Deye inverters are engineered with military-grade components and advanced thermal management systems, ensuring stable performance even in extreme temperatures. Their proven track record in residential and commercial installations worldwide speaks to their durability and trustworthiness.
4. How much money can I actually save with this system?
Homeowners typically see 60-90% reductions in their electricity bills by combining solar generation with intelligent battery storage. The system optimizes energy usage by storing solar power for nighttime use and leveraging time-of-use rate arbitrage where available.
5. Is this inverter compatible with my existing solar panels?
Absolutely! Deye hybrid inverters work with all major solar panel brands and technologies, including modern high-efficiency PERC and bifacial panels. Their wide MPPT voltage range (90-450V) ensures optimal performance with various panel configurations.
